Plywood For Construction
  • Bamboo wall and column plywood formwork
  • Bamboo wall and column plywood formwork
  • Bamboo wall and column plywood formwork
  • Bamboo wall and column plywood formwork

Bamboo wall and column plywood formwork

  • Size: 1220*2440(8~20)mm/915*1830*(9~10)mm
  • Normal Thickness: 8mm/9mm/10mm/12mm
  • Glue: Phenolic glue
  • Material: 100% bamboo
  • Application: bamboo shuttering formwork for concrete construction is widely used for housing building, bridge, viaduct, dam, tunnel, subway, cast-in-situ concrete application,and also for various containers’ flooring,packing boxes,vehicle and train bottom flooring, s

We are here to help:Easy ways to get the answers you need.

  • Describe
  • Parameter
  • Packaging
  • Daily Output
  • Case
1,Product Introduction

ZNSJ high strength Bamboo wall and column plywood formwork  is formed at high temperatures and pressures using the structure of “bamboo mat+thin bamboo
curtain+special phenolic glue”.  The special phenolic glue is research-developed by the specialist in Central South University of Forestry and Technology,
which is higher 2-3 baume degree than counterparts in glue adhesiveness and concentration. Therefore our high strength bamboo plywood have the
characteristics of higher bonding strength, higher waterproof, no tacking, and its turnover use time will be more than 20 times.

2,Product Advantages

1)Bamboo plywood is with glossy and smooth surface;

2)Multi- using times and long lifespan :

3)Good water resistant performance;

4)Low thermal conductivity;

5.Bamboo plywood have big size and can be sawed and nailed, which can effectively reduce the quantity of  supporting formworks.




Items

Parameters

Product Name

Bamboo plywood,  packing plywood, commercial plywood, Film faced Plywood ,

Bamboo wall and column plywood formwork  bamboo formwork, bamboo board,  bamboo

pannel,  bamboo plywood for construction

Specifications

1220*2440*(8-20)mm    1830*915*(9-10)mm

Glue

Phenolic glue

Materials

Bamboo

Moisture Content

≤10%

Density

≥0.90g/m3⊥

Water Absorption

≤10%

Modulus Of Elasticity

 //≥7×103N/mm2 ⊥5×103N/mm2

Modulus Of Rupture

//≥90N/mm2  //≥60N/mm2

Impact Strength

≥60Kg/m2

Bonding Strength

≥0.80N/mm2

Abrasion Value

<0.80g/100r

Using times

10-15times

Preservation Stregth

//≥60N/mm2 ⊥≥40N/mm2








Specifications

Thickness(mm)

Weight(kg/piece)

 1 20ft can load(pieces)

1.22*2.44

8

20.24

990

9

22.77

880

10

25.3

792

11

27.83

720

12

30.36

660

13

32.89

609

14

35.42

566

15

37.95

528

16

40.48

495

17

43.01

466

18

45.54

440






 Daily Output of Bamboo wall and column plywood formwork  is about 1000~2000pieces. If you want to order bamboo plywood , please advance 7~10days before loading date.Generally there are 10000~20000pieces of  bamboo plywood for construction with different sizes in our warehourse.
Welcome to visit our factory!
